Main Features:

• Bilingual (Chinese/English) interface with free switching;

• Supports 80 channels stacked on the same platform;

• Each channel (handheld or bodypack) can be switched with one button, with independent parameter settings;

• Uses lspro's proprietary noise reduction technology with ultra-cardioid capsule module, completely eliminating friction noise;

• lspro anti-pop audio processing technology prevents popping sounds from the mic;

• True automatic diversity reception;

• Latest technology audio circuitry for cleaner and fuller sound quality;

• Built-in spectrum analyzer to quickly scan and clearly display frequencies with interference;

• Integrated solid aluminum alloy side panel design;

• 600 freely selectable frequency points, 32 preset channels without mutual interference;

• All functions operated via one-button jog control;

• Transmitter has MUTE and lock operations;

• Allows custom naming for microphone users;

• Receiver display uses dual-color design: red in standby, orange when mic signal is received;

• Receiver antenna base provides 12V (80mA) power output for directional antennas.

Specifications:

Chassis: EIA standard 1U

Channel Groups: Dual channel

Frequency Stability: ±0.005%, controlled by PLL phase-locked loop

Carrier Frequency Band: UHF 603-935 MHz

Factory Preset Channels: 32 preset channels

Effective Working Distance: Generally 90 meters (open space)

Oscillation Method: PLL phase-locked loop frequency control

Sensitivity: S/N >60dB at 6dBμV input with 25KHz deviation

Bandwidth: 30MHz

Maximum Deviation: ±45KHz

Overall S/N Ratio: >105dB

Total Harmonic Distortion: <0.7% @ 1KHz

Frequency Response: 45Hz～18KHz ±3dB

Power Supply: 100-240V AC 50/60 Hz, 10W
