TX-12M
TX-12M is a 2-way coaxial loudspeaker, designed for using as stage monitors or for using as side/rear fills. It is with 1 x 12inch LF driver for low frequency and 1.7inch HF driver. The TX-12M offers an exceptional dynamic reproduction and impressive power, complex passive filtering ensuring very high fidelity and reliability.
Technical Data
Rated Power: 400W RMS
Program Power: 800W RMS
Components [Coaxial]: LF 12inch + HF 1.7inch
Connection: 2 x Neutrik Speakon (4 Pins)
Sensitivity (1W @ 1M): 95dB
Maximum SPL: 120dB Peak @ 1M
Horn Dispersion: H 40 x V 90 degree
Crossover point: 1.8 KHz
Impedance: 8 Ohm
Frequency Range: 60 Hz ~ 20 KHz
Color: Black or White
N.Weight: 18kgs
Cabinet Dimension (W x D x H): 424 x 513 x 388mm
Packing Dimension (W x D x H): 588 x 464 x 494mm
Rec. Amplifier Power: 400 ~ 800W 8Ohm
Applications: Quality PA & Stage Monitor. Portable PA System, Clubs & Discotheques etc.
