The CT-12 designed for use as stand-alone full-range or working with the sub woofer (e.g. TX-12B or TX-212B). Dedicated speaker management processor is recommended for better audio performance and speaker protection. The CT-12 can be flying up by M8 eye-bolt allows precise vertical or horizontal coverage choices, 35mm pole mounts on the bottom of the cabinets for positioning on a general purpose speaker stand or mast inserted in top-fitted stand adapters on the sub woofer cabinets. Waterproof cover bag is available for road rock events.

Technical Data

Rated Power: 400W RMS
Program Power: 800W RMS
Components: LF 12inch + HF 1.7inch
Connection: 2 x Neutrik Speakon (4 Pins)
Sensitivity (1W @ 1M): 98dB
Maximum SPL: 122dB Peak @ 1M
Horn Dispersion: H 90 x V 80 degree
Crossover point: 1.8 KHz
Impedance: 8 Ohm
Frequency Range: 60 Hz ~ 20 KHz
Color: Black or White
N.Weight: 24kgs
Cabinet Dimension (W x D x H): 370 x 385 x 620 mm
Packing Dimension (W x D x H): 460 x 445 x 680 mm
Rec. Amplifier Power: 600 ~ 800W 8Ohm
Applications: Hotel Conference Rooms, Hotel Halls, KTV Rooms, Portable PA System, Clubs & Discotheques etc.
