CT-10

The CT-10 designed for use as stand-alone full-range or working with the sub woofer (e.g. TX-12B or TX-212B). Dedicated speaker management processor is recommended for better audio performance and speaker protection. The CT-10 can be flying up by M8 eye-bolt allows precise vertical or horizontal coverage choices, 35mm pole mounts on the bottom of the cabinets for positioning on a general purpose speaker stand or mast inserted in top-fitted stand adapters on the sub woofer cabinets. Flight case and water proof cover bag is available for road and rock events

Technical Data

Rated Power: 300W RMS
Program Power: 600W RMS
Components: LF 10inch + HF 1.7inch
Connection: 2 x Neutrik Speakon (4 Pins)
Sensitivity (1W @ 1M): 93dB
Maximum SPL: 115dB Peak @ 1M
Horn Dispersion: H 90 x V 80 degree
Crossover point: 2 KHz
Impedance: 8 Ohm
Frequency Range: 65 Hz ~ 20 KHz
Color: Black or White
N.Weight: 17kgs
Cabinet Dimension (W x D x H): 320 x 370 x 540 mm
Packing Dimension (W x D x H): 445 x 395 x 620 mm
Rec. Amplifier Power: 300 ~ 600W 8Ohm
Applications: Disco Club, DJ Monitor, Quality PA & Stage Monitor. Portable PA System, Shopping Mall etc.
