TV-15
Detailed description:
TV-15 is a professionally designed two-way speaker with sweet and round sound, abundant power, powerful and full low frequencies, clear and delicate high frequencies, and strong penetration. The TV-15 speaker adopts a 15 inch 300W RMS power unit and a 1.7-inch high-frequency driver, and the high-frequency horn can be adjusted according to the needs of the occasion. It can be fixed on the wall or hung with M10 suspension rings. The box is treated with high-quality paint and the appearance color can be customized according to customer needs.
Product Parameters:
Model: TV-15
Rated Power: 300W RMS
Peak Power Program: 600W RMS
Unit Accommodation Components: LF 15inch+HF 1.7inch
Connection: 2 x Neutrik Speakon (4 Pins 1+1-)
Sensitivity (1W @ 1M): 96dB
Maximum SPL: 121dB Peak @ 1M
Horn Dispersion: H 90 x V 80 degrees
Crossover point: 1.8 KHz
Impedance: 8 Ohm
Frequency Range: 50Hz~20 KHz
Color: Black or White
Net weight: 24kgs
Cabinet Dimension (W x D x H): 440 x 397 x 754 mm
Packing Dimension (W x D x H): 515 x 472 x 814 mm
Combined with amplifier power Rec. Amplifier Power: 450~650W 8Ohm
Size & Specification:
Cabinet Dimension (W x D x H): 440 x 397 x 754 mm
Packing Dimension (W x D x H): 515 x 472 x 814 mm
